Overview
Main Features
CandidTech's LVDS camera with fakra interface offer superior performance and reliability in current automotive applications.
High-resolution LVDS automotive camera with 2 megapixels, providing exceptional clarity in day and night scenes.
CandidTech’s LVDS cam can integrate multiple features, such as backup camera,360 surround view, dashcam, DMS driver monitoring system, OMS occupant monitor system, streaming rearview mirror, and more.
LVDS transmission is characterized by high definition, low latency and high stability, and is suitable for a variety of vehicle application scenarios, including passenger cars, commercial vehicles, buses, agricultural vehicles, mining vehicle, etc.
Small size compact design, good concealment of installation, does not affect the vehicle's appearance.
Main Specifications
| Sensor | OmniVision |
| ISP | NEXTCHIP |
| Lens | 4G2P+1IR |
| Aperture | F2.0 |
| FOV | H:110°±3° V:58±3° |
| Resolution | 1920*1080 |
| Frame rate | 30fp/s |
| Serializer | MAX |
| Transmission | GMSL2 |
| Video format | YUV422 |
| Synchronization | Support |
| LFM | Support |
| HDR | 120dB |
| Start-up time | <1S |
| Working voltage | DC 7-16V |
| Working current | <200mA(DC 8V) |
| Quiescent current | none |
| Interface | FAKRA |
| Power supply | POC |
| Storage temp. | —40℃～+85℃ |
| Working temp. | |
| Waterproof rating | IP66 |
| Size | 25*25*34.5mm |
More about the CandidTech
Factory price with strong market competitiveness.
Leading R&D technology capability.
Support OEM&ODM service.
20 years service experience for domestic and foreign mainstream OEM customers.
Own Automatic AA camera production line and front-end equipment.
OE automotive grade quality by full process controlling, good product consistency and stability.
30 days supply delivery.
3 years after-sales guarantee.
Our current product lines cover vehicle cameras for different applications: including rear view, front view, side view and around view, Dash Cameras, Around View Monitoring Systems, ADAS products,CMS(Camera Monitor System) ,OMS(Occupant monitor system),DMS(Driver Monitor System), and the like. Please email:sales2@candidelectronics.com for more details.
|
